tracing its roots back to 1952, rubycon is one of the original pioneers in the aluminum capacitor market. with monthly production of up to 1 billion capacitors from over 8,000 product items, rubycon ranks as one of the largest suppliers of miniature electrolytic capacitors.
| Part Number | 25LSQ56000MEFC36X118 |
|---|---|
| Part Status | Active |
| Capacitance | 56000µF |
| Tolerance | ±20% |
| Voltage - Rated | 25V |
| ESR (Equivalent Series Resistance) | - |
| Lifetime @ Temp. | 3000 Hrs @ 85°C |
| Operating Temperature | -40°C ~ 85°C |
| Polarization | - |
| Applications | General Purpose |
| Ripple Current - Low Frequency | 8.4A @ 120Hz |
| Ripple Current - High Frequency | 9.072A @ 10kHz |
| Impedance | - |
| Lead Spacing | 0.500" (12.70mm) |
| Size / Dimension | 1.417" Dia (36.00mm) |
| Height - Seated (Max) | 4.803" (122.00mm) |
| Surface Mount Land Size | - |
| Mounting Type | Chassis Mount |
| Package / Case | Radial, Can - Screw Terminals |
Manufacturer: Rubycon
Description: CAP ALUM 56000UF 20% 25V SCREW
In Stock: 0
