murata power solutions designs and manufactures dc/dc converters, ac/dc power supplies, magnetics, data acquisition devices and digital panel meters, and offers these products in custom, standard and modified-standard variations.
| Part Number | 18R103C |
|---|---|
| Part Status | Active |
| Type | Wirewound |
| Material - Core | - |
| Inductance | 10µH |
| Tolerance | ±10% |
| Current Rating | 3.45A |
| Current - Saturation | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 15 mOhm Max |
| Q @ Freq | 59 @ 500kHz |
| Frequency - Self Resonant | 23.8MHz |
| Ratings | - |
| Operating Temperature | 0°C ~ 70°C |
| Frequency - Test | 1kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder |
| Supplier Device Package | - |
| Size / Dimension | 0.539" Dia (13.70mm) |
| Height - Seated (Max) | 0.625" (15.90mm) |
