hotenda.cn is an authorized distributor of on semiconductor/fairchild products. on semiconductor/fairchild is a leading supplier of high performance, multi-market semiconductors.
| Part Number | FDMS8570SDC |
|---|---|
| Part Status | Active |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 25V |
| Current - Continuous Drain (Id) @ 25°C | 28A (Ta), 60A (Tc) |
| Drive Voltage (Max Rds On,Min Rds On) | 4.5V, 10V |
| Vgs(th) (Max) @ Id | 2.2V @ 1mA |
| Gate Charge (Qg) (Max) @ Vgs | 42nC @ 10V |
| Input Capacitance (Ciss) (Max) @ Vds | 2825pF @ 13V |
| Vgs (Max) | ±12V |
| FET Feature | Schottky Diode (Body) |
| Power Dissipation (Max) | 3.3W (Ta), 59W (Tc) |
| Rds On (Max) @ Id, Vgs | 2.8 mOhm @ 28A, 10V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | Dual Cool™56 |
| Package / Case | 8-PowerTDFN |
