| Part Number | CI201210-R22J |
|---|---|
| Part Status | Obsolete |
| Type | Multilayer |
| Material - Core | Ceramic |
| Inductance | 220nH |
| Tolerance | ±5% |
| Current Rating | 250mA |
| Current - Saturation | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 2 Ohm Max |
| Q @ Freq | 10 @ 50MHz |
| Frequency - Self Resonant | 330MHz |
| Ratings | - |
| Operating Temperature | -25°C ~ 100°C |
| Frequency - Test | 50MHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | 0805 (2012 Metric) |
| Supplier Device Package | 0805 (2012 Metric) |
| Size / Dimension | 0.079" L x 0.049" W (2.00mm x 1.25mm) |
| Height - Seated (Max) | 0.047" (1.20mm) |
